Also known as a Corsi-Rosenthal box, this DIY method of building your own air filter with MERV13 furnace filters and a box fan are an easy and cost-effective way to help clear indoor air from airborne virus particles, wildfire smoke, pollen, dust, and more!
If you can seal a box, you can build one (or 100!) of these!
Image / Video Gallery
This gallery includes photos of builds, creative modifications, instructional images, as well as videos. Click through tags below to load more.
Video: How to effectively ventilate classrooms using fans, HEPA filters or Corsi-Rosenthal box fans and monitors
Cleaning indoor air properly greatly reduces infections by airborne viruses, like COVID-19. This video explains it all very well!
How to build a Corsi-Rosenthal box fan filter
Start here
A Variation on the “Box Fan with MERV 13 Filter” Air Cleaner Article by Jim Rosenthal
Read about it in WIRED: https://www.wired.com/story/could-a-janky-jury-rigged-air-purifier-help-fight-covid-19/
Construction Guide:
More details, including filter brands to avoid, here: encycla.com/Corsi-Rosenthal_Cube (by Philip Neustrom)
(hint: Filterbuy MERV-13, prevalent on Amazon, have not tested well)
Illustrated Guide
The Fan Shroud
An optional part of a box fan filter is the fan shroud, or covered fan corners. Covering corners of a square box fan closes gaps and improves efficiency of the fan. See Jim Rosenthal’s article about it here. Use cardboard or duct tape.
Testing to optimize fan shroud size. David Elfstrom found a 13.5 to 14.25 inch diameter opening to work best with a Utilitech brand fan. Lasko fans work best with a 15 inch fan shroud.
Choosing filters
David Elfstrom advises “keep an eye out for local sales on the 20x20x1 or 20x25x1 Filtrete 1900 and box fans“
To build with 2 inch deep filters, use (3) 20x20x2 and (2) 16x20x2
You can order a full set of high-quality MERV13 filters to make this air purifier here: https://www.texairfilters.com/filters-for-box-fan-and-merv-13-filters-air-cleaner
These 2 inch deep filters (compared to typical 1 inch) provide greater surface area for filtration, better air flow, quieter operation, and longer filter life.
Performance
The Corsi-Rosenthal box (single filter tested, full cube would be even better!) performs very well! It is the most cost effective air cleaner on Marwa Zaatari’s chart!
From Bill Bahnfleth, Chair – ASHRAE Epidemic Task Force
source: https://twitter.com/WBahnfleth/status/1469454061225316353?s=20
source: https://twitter.com/WBahnfleth/status/1469781099043864583
CR Boxes in Johns Hopkins “Ventilation: Vital Tool to Reduce Spread”
source: https://twitter.com/MarinaC_Dyb/status/1469469896664829952?s=20
Round Fan alternate design
Not all parts of the world have box fans available. This international team has worked out an alternate design using a round fan!
Travel DIY Air filter
Modification: Screen as “prefilter”
This modification, adding fiberglass screen material, can keep pet hair out of filters and prolong their useful life, with barely noticeable flow reduction!
FAQ – Frequently Asked Questions
New comprehensive FAQ page here!
Also, tons of details and FAQs in this excellent comprehensive thread by Lazarus Long.
Video: Box Fan Filter build tutorial – Spanish
source: AleHSalcedo2
Video: A Fourth Grader Explains How to Build a DIY Corsi/Rosenthal Box Air Cleaner
source: @gbignami
Mass production!
Check out how Rosie @BkPhilanthropy assembled and distributed 100 air filters!
Download the printable PDF of the insert they included with the filters!
Dr. Prather with UCSanDiego
Brown University
Students unite to take a hands-on, DIY approach to improving air quality
An event hosted by Brown’s School of Public Health brought students together to build low-cost, highly effective Corsi-Rosenthal cubes as air filters that will augment existing filtration systems at Brown.
www.brown.edu/news/2021-11-19/diy
Common concerns addressed
Developed by @amandalhu, this interactive PDF addresses common points of confusion around air filters.
Rebuttal Matrix for Advocates of Air Filtration in Schools Based on Common Barriers
